Korsch PH230 Rotary tablet press
Pre owned machine
- Robust and efficient
- Very low operating hours – very good condition
- Complete documentation
- Equipping with TabCon-Series recommended
- Retrofits possible according to your requirements
- Delivery of tableting tooling
| Manufacturer | Korsch |
| Machine type |
PH230 |
| Year of manufacture | 1993 |
| Tool type | EU-1″ / EU-D |
| Tool stations |
14 |
| Key grooves |
Upper and lower |
| Main compression force max. | 60 kN |
| Precompression force max. | 15 kN |
| Tablet diameter max. | 25 mm |
| Filling max. | 22 mm |
| Punch separation max. | 11 mm |
| Tablet output max. | appr. 65.000 pc/h |
| Measuring points | Main compression |
| Feeder type | Force feeder |
| Dimensions fully | W750 x D930 x H1.725 mm |
| Weight | 1450 kg |
| Power supply | 400V, 3Ph + N, 50Hz |
Purchase of Pre-Owned Machines
If you have surplus tablet presses in your laboratory, development department or production, please let us know.
